Rikon 17" VS Drill Press

SKU: M694196 30-217
Write a Review
$1,574.00
SKU:
M694196 30-217
Availability:
Ships direct from manufacturer. Lead times may vary.
prop65:

Frequently Bought Together

Please choose options for all selected products

  • Choose Options

Description

17" Variable Speed Floor Drill Press #30-217 is the best in the 17" class. Designed with features that woodworkers have demanded – more powerful motor, Vari-speed pulley that adjusts the chuck speed with a simple turning of a lever, speeds from 200-700 RPM or 600-2,300 RPM – a digital RPM display, rotating work table with clamp-friendly thin edges, large 6" spindle travel, and a handy LED light.

  • Powerful 1.5 HP motor
  • Variable speeds
  • Clutch depth stop
  • Cast iron table
  • Large cast iron feed handles
  • Mfr.'s 5-year warranty

Volts: 115/230V, 60Hz
Horsepower: 1-1/2 HP
Amps: 13.3/6.7
RPM: 1,720
Swing: 17"
Chuck Size: 5/8"
Chuck Taper: JT3
Drilling Capacity: 1"
Spindle Travel: 6"
Spindle Taper: MT2
Head Rotates: 360°
Speeds: Variable 200 – 700 / 600 – 2,200
Quill Diameter: 2-5/8”
Table Dimensions: 14" x 14"
Table Tilts: 90°
Table Rotates: 360°
Maximum Chuck to Table: 27-3/4"
Maximum Chuck to Base: 46-5/16"
Column Diameter: 3-1/8"
Overall Height: 70-1/8"
Base Size: 19-7/8" x 13-1/2"
Weight: 192 lbs.

Please specify voltage. 115V will be shipped if not specified.
