Skil
In the latest addition to SKIL's table-saw lineup, their legendary Worm Drive power train gearing gives you maximum torque at 3-5/8" depth of cut and 30-1/2" rip capacity. Cutting through plywood and slicing with 4 times the ease and precision helps increase productivity for faster student projects.
The rack and pinion system makes fence adjustments quick and smooth for accurate cuts. The patented 15 amp Dual-Field™ Motor runs cooler so it'll work harder, longer and more efficiently in any classroom. This unit comes with a rugged rolling stand and 16" wheels that help it remain stable and easily move over rough or uneven surfaces so you can push it around the classroom easily and set up quickly.
Clean-up is easier and faster with the dust port elbow which contains all debris to one area. The outfeed and left support enable a single user to make larger cuts so kids have more independence while creating.
Blade Arbor Hole Diameter: 5/8"
Blade Diameter: 10"
Max. Cutting Depth 90°: 3-5/8"
Max. Cutting Depth 45°: 2-3/10"
Max. RIP of Left of Blade: 16-1/2"
Max. RIP of Right of Blade: 30-1/2"
Max. Width of Dado: 0.5"
Max. bevel angle: -1° to 47°
No Load Speed: 5000 rpm
Teeth of Blade: 24
Tool Current Rating: 15 Amps
Tool Weight: 52.9 lbs.
Includes
blade
miter gauge
Smart Guard System with Anti-Kick Back Device
dust elbow
insert plate
push stick
wrench
rip fence
