Bosch REVOLVE2000 Self-Leveling Horizontal/Vertical Rotary Laser Kit

SKU: M258920 GRL2000-40HVK

Write a Review
$1,000.00
SKU:
M258920 GRL2000-40HVK
View-Catalog-Page:
184

Frequently Bought Together

Please choose options for all selected products

Description

This Rotary Laser Kit delivers a comprehensive solution for precise outdoor and indoor leveling. Manual Dual Slope allows the user to adjust the slope angle on the laser on both the X- and Y-axes. Features a horizontal/vertical self-leveling laser, suitable for leveling and aligning applications. The laser delivers ±1/16" accuracy at 100' and a working range of up to 2,000', with the included receiver. The electronic self-leveling system has a disturbance monitor, which indicates if tool position changes, ensuring consistent leveling accuracy on the jobsite. The laser has a red metal cage for durability.

Features

  • Complete kit – features a laser receiver, tripod, grade rod, remote control, wall mount and all-in-one hard carrying case
  • All-in-one hard carrying case – designed to hold included accessories: receiver with bracket, tripod, grade rod and more
  • Manual Dual Slope – allows the user to adjust the slope angle on the laser on both the X- and Y-axes
  • Electronic self-leveling – allows for easy setup and use on the job
  • Disturbance monitor – indicates if tool position changes, ensuring consistent leveling accuracy
  • Reliable accuracy – delivers ±1/16" accuracy at 100'
  • Long working-range capability – provides up to 2,000' working range
  • Laser receiver with mounting bracket – allows for easy-to-read LCD dual display and easy attachment to leveling rod
  • Vertical-beam functionality – provides a vertical beam at 90° point for layout, squaring and plumb applications
  • Lightweight aluminum tripod – features quick-clad release on legs and durable finish
  • Robust design – features cage overmold and two large easy-to-grip carrying handles for convenience and additional drop protection

Specifications

Accuracy: ± 1/16" @ 100-ft.
Battery: 1.5V
IP Rating: IP 56
Laser Diode: Class 3R <5mW @ 630 ~ 670nm
Leveling Type: Self-Leveling, Up to 5°
Material: Plastic Composite
Mount Threading: 5/8-11
Operating Temperature: 14° F / -10° C ~1 22° F / 50° C
Range: Up to 2,000'
Size: 7.5"H x 7"L x 6.7"W
Weight 3.9 lbs.

What's in the box

(1) GRL2000-40HVK REVOLVE2000 Self-Leveling Horizontal/Vertical Rotary Laser
(1) LR20 Laser Receiver with Bracket
(1) BT160 Aluminum Contractor Tripod
(1) GR13 13 Ft. Grade Rod
(1) Red Laser Glasses
(1) Red Target Plate
(1) RC4 Remote Control
(1) WM4 Wall Mount
(4) AA Batteries
(2) D Batteries
(1) All-In-One Hard Carrying Case
