Afinia H+1 3D Printer

SKU: M190520 33359
Write a Review
M190520 33359
Ships direct from manufacturer. Lead times may vary.
Acrylonitrile, Butadiene, Styrene
Product Type:
Desktop 3D Printer

Frequently Bought Together

Please choose options for all selected products


The Afinia H+1 is perfect for serious educators, engineers, and hobbyists. With intuitive software and features like fully-automated platform leveling, material-specific printheads, dual air filtration, and more, the H+1 is a top-of-the-line 3D printer. Plus, Afinia offers unbeatable and unlimited lifetime phone support, and a one-year warranty.

The Afinia H+1 3D printer combines a large build volume with consistency of performance. Material-specific printheads are included, ensuring optimal print quality and compatibility across a wide range of filament types.

  • Automated leveling and height sensing
  • Power loss print recovery filament run-out detection
  • Print queue for auto job management
  • Large build volume (10" x 8" x 8.8")
  • Smart support material technology
  • Multiple connectivity options (WiFi, USB, LAN, & USB Flash Drive)
  • Power loss print recovery filament run-out detection

New features to the H+1

  • Material-specific printhead system for optimal quality and compatibility
  • Circulating dual-filtered system
  • 2-sided interchangeable build plates
  • Customizable temperature controls & filament profiles
  • Enclosed, heated platform & chamber

Out-of-the-Box 3D Printing
The Afinia H-Series 3D Printers provide a true "Out-of-the-Box 3D Printing Experience" as the 3D Printers comes fully assembled with easy-to-install software for both the PC and Mac.

Improved Material Compatibility
The Afinia H+1 comes with three material-specific printheads: ABS, PLA, and TPU. In contrast to the one-size-fits-all extruder, these interchangeable heads are designed specifically for each material’s characteristics, allowing for greater filament control and a better finish.

Easy to Use, Powerful Software
The 3D Printer Software features an easy-to-use interface for laying out, orienting, duplicating, and scaling parts. Simply use the included utility to calibrate the printhead height, and within minutes you are printing. It easily imports STL files, and the output can be customized in terms of the amount of support material and "raft" (base support) printed. Break-away support material is simple to remove, and tools for aiding the break-away are included. Design files for 3D printing can be created using online software, professional software such as SolidWorks™, or by downloading from the extensive online 3D printer community for free.

Build Volume: 10"W x 8"D x 8.8"H (255 x 205 x 225mm)
HD Print Quality: 0.05mm (100 micron), 0.1 mm, 0.15 mm, 0.2mm, 0.25mm, 0.3mm, 0.35mm, 0.4mm
Smart Support: Support material automatically created by 3D printing software
Safety: Built-in HEPA and activated carbon filters remove microfine particles
Display: 4.3" full-color touchscreen LCD
File Formats: .stl, .obj, .3mf, .up3, .ups, .ply, .off, .3ds, .gcode
Dimensions: 19.6"W x 18.1"D x 20.5"H (460 x 500 x 523mm)
Weight: 66.2 lbs. (30 kg)
Power: 110-220VAC, 50-60Hz, 220W; With power loss print recover
Connectivity: WIFI, USB, USB Flash Drive, LAN (with ability to disconnect from computer when print job starts
Materials: 1.75mm ABS, PLA, TPU, PC, PETG, or Flexible Filament; With filament run-out protection (included: 1 x 500g spool of filament)
Software: Windows 7 or higher (32/64 bit)and MAC OSX 10.7+, iOS
