SawStop Floating Overarm Dust Collection Guard

SKU: M771600 TSG-FDC
Write a Review
$495.00
SKU:
M771600 TSG-FDC
View-Catalog-Page:
379
prop65:

Frequently Bought Together

Please choose options for all selected products

Description

This heavy-duty 4" overarm is designed to provide operator protection while removing table-top dust in both standard and non-through cuts. The transparent blade cover is engineered to lift easily for quick blade access, and the rigid steel overarm swings smoothly away and back into operating position. The wide pipe allows for high air volume collection.

  • Compatible with most ICS, PCS & CNS configurations
  • Mfr.'s 1-year warranty

Specifications

Blade Guard Dimensions: 3-1/2" x 18-1/2"
Distance between blade and end of extension table: 35-3/4" to 68"
Inner Dust Tube Diameter: 3"
Outer Dust Tube Diameter: 4"
Outer Dust Tube height above table: 13-1/2"
Outer Dust Tube height above floor: 33-1/2" to 50"
Weight: 58 lbs.

What's in the box

Extension Leg
Dust Collection Guard Mounting Bracket
(2) Leg Support Bracket
Outer Dust Tube
Inner Dust Tube
Floating Dust Collection Blade Guard
Owner's Manual
Hardware Pack

Download Manual

Resources
