Rikon Wall-Mounted Dust Collector

Description

Perfect for small shops with limited floor space, mounting this powerful dust collector near your most used machines is ideal for always having it connected and operating while you work. The 10” spiral impeller creates big CFM suction to whisk away the wood chips and dust from bandsaws, planers, jointers or sanders. A dual 4” inlet fitting with cover cap permits the collector to be connected to two machines.

Motor: 1HP, TEFC
Motor Speed (no load): 3,450 RPM
Amps, Hertz, Phase: 7 A / 3.5 A, 60 Hz, 1 Ph
Dust Collection Velocity CFM: 800 @ 4” or 1,100 @ 5” inlet
Max. Static Pressure (at 0 CFM): 7.2”
Blower Impeller: 10” Diameter, Aluminum
Sound Rating @ 6 Feet: <86.375 dB
Canister Filtration Rating: 1 Micron
Filtration Efficiency: 99%
Canister Pleated Filter Size: 19-5/8” x 7-1/8”
Total Pleated Filter Surface: 13.46 sq/ft
Filter Cleaning Method: Hand crank, internal rotating flapper
Plastic Bag Length (installed): 20”
Plastic Bag Capacity: 1.5 Cu. Ft.
Dust Ports / Hose Connections: 1 @ 5”, 2@4”
Intake Funnel Size: 5” diameter
Machine Certification: All metal frame

Includes wall mounting bracket, pleated canister filter with cleaning handle assembly, disposable plastic dust bag, strap clamp, dual 4” inlet fitting, 4” inlet cap, on/off safety switch and instruction manual.
