Metabo HPT 10" Dual Slide Compound Miter Saw with Laser Marker

SKU: M616515 C10FSHSM
Write a Review
M616515 C10FSHSM

Frequently Bought Together

Please choose options for all selected products


Sliding 10" dual compound miter saw with laser marker offers the ultimate in form and function for trim carpenters, framers and woodworkers. The positive stops on the miter and bevel scales make for easy-to-read measurements and quick settings. With a 45° dual bevel angle range, users can quickly flip the saw blade and leave the material in place. The linear ball bearing slide system and white on black miter scale provide superior accuracy and visibility. Electronic speed control keeps RPM's constant and unintended cuts are avoided with the electric brake feature.

  • Compliant with new UL regulations
  • Adjustable laser marker for precise cutting lines easily adjustable to users preference
  • 12 Amp motor for the toughest cutting jobs
  • 57° miter angle to the right, 45° degree miter angle to the left
  • 0-45°e bevel angle range to the right and left
  • Positive stops on miter and bevel scale for easy-to-read measurements and quick settings
  • Linear ball bearing slide system with white on black miter scale
  • Electronic speed control maintains RPM while cutting and improves control
  • Soft start function, reduced noise and recoil during start-up
  • Adjustable pivot fence broadly supports work piece for improved stability while cutting
  • Electric brake halts the rotation of the blade preventing unintended cuts
  • Carbon brush access allows user to replace brush
  • Highly efficient dust collector attachment
  • Splinter guard prevents material from splintering

Voltage: 120
Amps: 12
Laser Marker: Yes
No-Load Speed: 3,800 RPM
Blade Diameter: 10"
Arbor Size: 5/8"
Bevel Angle Range: R & L: 0-45°
Bevel Cross Cut at 90° (L): 2-3/16" x 12"
Bevel Cross Cut at 90° (R): 1-3/16" x 12"
Bevel Stops: Right and Left: 0° and 45°
Miter Angle Range: Right: 0-57°
Miter Cross Cut at 57° (R) : 3-11/32" x 6-1/2"
Miter Angle Range: Left: 0-45°
Miter Cross Cut at 45° (L/R): 3-11/32" x 8-19/32"
Miter Detent Stops: Right and Left: 0°, 15°, 22.5°, 31.6° and 45°
Miter 45° (L/R) + Bevel 45° (L): 2-3/16" x 8-19/32"
Miter 31° (L) + Bevel 45° (R): 1-3/16" x 10-7/32"
Miter 45° (L/R) + Bevel 45° (L): 1-3/16" x 8-19/32"
Weight: 45.9 lbs.

10" 40T TCT saw blade
Pivoting flip fence
10mm box wrench
Dust bag
