Laguna 8" JX/8 Quadtec Jointer 110V

SKU: W502081 MJ8X72E-0130
Write a Review
W502081 MJ8X72E-0130

Frequently Bought Together

Please choose options for all selected products


The QuadTec II cutterhead produces an amazing surface finish on all woods including difficult hardwoods. It uses 4-sided carbide insert knives that are quieter and more durable compared to straight HSS knives. They can be rotated for a new cutting edge without the need for a knife setting jig.

Table depth adjustments travel along an arc to keep the same distance to the cutterhead through its travel. Emergency Knee Stop uses a body-length bar at knee height to shut off the jointer. The machine body has been redesigned with a toe-kick to allow the user to position themselves closer to the machine tables and to move safer and easier along the length of the machine. Infeed tables are now fitted with pull-out support roller to help support longer materials.

Motor: 110V 1.75HP 1-Phase 60hz/15 Amp
CSA: Yes
Bed Size: 8" x 72"
Infeed Table Pull-Out Extension: 8"
Rabbeting Capacity: 1/2"
Fence Size: 38" x 4-3/4" Cast Iron
Fence Tilt: ±45/90°
Max. Depth Of Cut: 1/8"
Table Height From Floor: 31"
Safety Bar Shut-Off: Yes
Bracket To Mount Light: No
110V Outlet For Light: No
Bracket To Mount Feeder: No
Dust Port Diameter: 4"
Plug (NEMA 5-15P): Yes
Insert Knives: 20 x 4-Sided Carbide, 4-Row Cutterhead RPM: 5500
Cutterhead Diameter: 3-1/8"
Bed Adjustment: Parallelogram
Dimensions Set Up: 75-1/2" x 26-1/2"
Base Footprint Dimensions: 32-1/2" x 15-1/4"
Shipping Dimensions: 40" x 18" x 26" 139 lbs. 82" x 25" x 17" 319 lbs. (2 Boxes)

2 push blocks
