Hamilton Buhl Small Media Production Studio Kit

Description

The HamiltonBuhl Small Media Production Studio Kit provides the versatility, functionality and unrivaled durability you need to produce high-quality, professional studio results!

HDV17BK ActionPro™ Camcorder
This is a full, high-definition 20MP Digital Video Camera that is slim, sleek and easy-to-use. ActionPro™ is the perfect video camera for any age. Featuring 2.7K HD 2688x1520 resolution, a 30 megapixel, 8.0M CMOS sensor, an 18x digital zoom and a rotating 3” IPS screen viewer progressive scan, the ActionPro™ camcorder delivers excellent image quality.

HDV17-MIC External Microphone For Camcorders And SLR Cameras
Easily mounts to camcorders and SLR cameras and is designed to improve sound recording quality with its high performance super-cardioid pickup and dual-head technology for long pickup distances (approx. 12'), NCR Noise Reduction Technology, wide frequency responses, and an external +20dB sensitivity enhancement switch to adapt to different sound intensity.

TPOD18 Octopus Mini-Tripod Camera Stand
This flexible, highly durable mini-tripod camera stand bends and flexes into any position! With 360° rotation capability, it is the ideal choice and accommodates most cameras. Includes easy-slide adapter for camera and smartphone.

9' x 60" Green Screen Backdrop Cloth
Perfect for chromakeying (filming in front of a pure-colored screen, typically green then replacing it with any scene or background to achieve special effects). Highly saturated for accurate color-balancing.

I Can Present Editing Software
Powerful editing software with teleprompter, split screen, picture-in-picture, scroll text features, chromakeying and more.

Animate-It! Stop-Motion Editing Software
Capture from any webcam to create stop-motion animations, import audio and video clips, use time-lapse feature, draw shapes, mask, and make titles, subtitlies and credits like a pro.

Specifications

HDV17BK Camcorder Specifications:

Video File Format: AVI
Video Resolution: 2.7K (2699x1520), FHD (1920x1080), HD (128-x720), VGA (640x480)
Zoom: 18x digital
Fixed Lens: F/2.6, f=7.0mm
Focal Range: 1mm~Infinity
Storage Media: Supports C10 (or higher) SD Card, Max. 128GB
Image Sensor: 30 Megapixels with 8M CMOS
Image Resolution:48M (8000x6000), 30M (6400x4800), 24M (5600x4200), 20M (5200x3900), 16M (4608x3456), 12M (4000x3000), 10M (3648x2736), 8M (3264x2448), 7MHD (3648x2048), 5M (2592x1944), 3M (2048x1536)
Still File Format: JPG
Built-in LED light
Face detection, anti-shake, self-timer and auto-power off
Language: Supports multiple languages
Screen: 3.0" IPS display with 270° rotation
PC Interface: Mini USB 2.0 Port (USB cable Included)
TV Output: Mini-HDMI (HDMI cable not included)
Rechargeable lithium-Ion battery (included separately, need to install)

HDV17-MIC Specifications:

Monomer: Electrostatic Capacitor Head
Pointing Feature: Super Heart Pointing
Frequency Response: 50Hz-16KHz
Sensitivity Enhancement: +20dB ±2dB
Sensitivity: -45dB ±3dB (0dB=1V/Pa @1KHz)
Equivalent Noise Level: 24dB (A)
Maximum Sound Pressure Level: 130dB (THD≤1.5% @1KHz)
Output Impedance: 200Ω ±30% @1KHz
Channel: Mono
Voltage: “AAA” 1.5V Alkaline battery
Power Consumption: ≤ 5mA (typical)
Battery Life: Approx. 60 hours with new battery

Universal Tripod TPOD18 Specifications:

Material: ABS, Rubber
Maximum load: 1 lbs
Cameras interface: universal 1/4-20 screw.
Tripod is lightweight and easy to use.
Works with smartphones (Apple or Android) in all size, cameras, webcams (we suggest you take your phone case off when using clamp).
The unique design allows you to secure your compact digital camera and video camera.
Flexible tripod can stand or wrap around base on almost any surface.

Universal Clip Specifications:

1 x Flexible Tripod, 1 x Universal Clip, 1 x Universal Clip Mounting Plate
Height with Phone Mount - 9.5 inches
Height without Phone Mount – 6.5 inches
Max Phone Mount Width - 3.3 inches
Min Phone Mount Width - 2.2 inches

Green Screen Backdrop Specifications:

Size: 9' x 60"
Color: Green
Material: Highly saturated 100% polyester

I Can Present Software Specifications:

Powerful editing software with teleprompter, split screen, picture-in-picture, scroll text features, chromakeying and more!

General Requirements:

Minimum of 1GB of free memory
Minimum Screen Size: 1024 x 768 Pixels
USB Webcam - included with HB Green Screen Production Kit
Windows PC Users - Minimum Recommended System Requirements:
A PC running Windows XP SP2 or later, Windows Vista or Windows 7.
Windows XP requires .Net Framework 3.5 SP2, available as a free download from Microsoft's website.
30MB of free Hard Disk space.

Mac Users - Minimum Recommended System Requirements:
Mac OS X 10.5 to Mojave 10.14.x (NOT AVAILABLE FOR CATALINA OS)
228 MB of Hard Disk space.

HB Animation Studio Kit Specifications:

The Animation Studio Kit includes a 5MP, 30FPS, gooseneck webcam with a non-slip base and Animate It! stop motion animation software, developed by the award-winning makers of "Wallace & Gromit."

Software Features Include:

Capture from any webcam
Use the software to take images using a USB webcam to create animation
Import Audio
Add an audio clip from your music library or record directly from the included webcam microphone
Drawing
Add 2D shapes to animations or as a masking tool
Import Video Images
Import both still images and video to use as a background in animations
Titles
Add the movie feel with titles, subtitles and credits
Time Lapse
Set up the camera and use the time lapse setting to record action over a long period of time
Cross Platform
Whether using a Windows or Mac computer, Animate It!

System Requirements:

Windows PC Users
Windows XP, Vista, 7,8 or 10
Microsoft .Net Framework 4 (available as a free download from the Microsoft website)
Graphics card recommended and should support DirectX 9 shader model 2.0
Mac Users
Intel Mac, OS X version 10.8 to Mojave 10.14.x (NOT AVAILABLE FOR CATALINA OS)
USB webcam (included with HB AnimateIt Studio Kit)
1.5GB RAM (2GB RAM recommended)
2GHz CPU
100MB HD space
NOTE: Download a FREE trial of software before entering License Key. Once key is entered, no software refund can be given.

Carry Case Specifications:

Durable, plastic construction
20" x 10" x 10"
3.02 lbs.
Recessed carry handle
Lockable (lock sold separately)

What's in the box

HDV17BK ActionPro™ Camcorder
HDV17-MIC External Microphone For Camcorders And SLR Cameras
TPOD18 Octopus Mini-Tripod Camera Stand
9' x 60" Green Screen Backdrop Cloth
I Can Present Editing Software
Animate-It! Stop-Motion Editing Software
LCP Plastic Carry Case (color is subject to change without notice)
