Full Spectrum Pro-Series Laser System, 24"x 16"

SKU: M416157 P2416
Write a Review
$9,445.00
SKU:
M416157 P2416
Availability:
Ships direct from manufacturer. Lead times may vary.
fbt-product:
71486

Frequently Bought Together

Please choose options for all selected products

Description

The next step in precision, power and performance. Designed for industry-scale production and heavy usage output. Now featuring LCD touchscreen controls and the powerful, easy-to-use RetinaEngrave v3.0 laser control software.

Exclusive innovations include feature-packed LCD touchscreen controls and the powerful, easy-to-use RetinaEngrave v3.0 laser control software, highlighting a full design suite and compatibility with Mac, PC or Linux. The new era of professional grade laser systems has arrived!

The Best Laser Control Software on the Market! This powerful, browser-based software lives right on your laser and is accessed using your favorite browser and operating system. Simply input the IP address of your machine into your browser address bar and you are ready to go. Best part? There's nothing to download, ever. Welcome to the future of laser control & design software!

  • Browser Based Software - No Internet Required. (Windows, Mac and Linux Compatible)
  • 7" LCD Touch Screen - Allows Users to Control Major Functions Right from The Machine
  • Rotary Attachment - (sold separately) Allows for Cylindrical Objects Such as Cups To Be Engraved
  • Motorized Z-Table - Enables Users to Fit Larger Objects Inside the Work Area
  • Pass-Through Doors - Large Sheets of Material Are No Problem with This Feature
  • Auto Focus - Makes Workflow Faster and More Precise
  • Mfr.'s 2-year Warranty plus Technical Support Via Phone and Email

Engraving Area: 24" x 16" (610mm x 406mm)
Machine Dimensions: 56" x 31.5" x 36.5" (1420mm x 800mm x 843mm)
Weight: 260lbs (110 kg)
Z-Table Range: 6.5"

Laser Classification: Class 3R
Laser Type: Sealed CO2 Laser Tube
Laser Power: 90W
Focus Lens Included: 2.5"

Power Supply: ​AC 110V native (220V option available)
Gross Power: < 1000W

Operation Modes: ​Precision Raster, Vector or Combined Modes
Motion Control: High-Speed Stepper Motors
Operating Temperature: 0C - 45C

Software: RetinaEngrave v3.0
Compatibility: PC, Mac & Linux
Browser Compatibility: Google Chrome (recommended), Safari, Firefox, Edge
File Import Options: JPG, PNG, BMP, TIFF, SVG, DXF, DWG
Minimum Screen Resolution: 1024 x 768 Pixels
Wireless Compatibility: Ability to Connect Through Local Network (Ethernet or Wireless) without Internet Connection
802.11n

Includes
Professional Series 24" x 16" 90W CO2 Laser
Water Chiller
Exhaust Fan
Air Compressor
Motorized Z-table with Auto-focus
Honeycomb Table
Knife Edge Table
RetinaEngrave V3
