Baileigh 1006852 Metal Ring Roller 220V

Description

Due to special pricing available exclusively to our school customers, this item is not available for purchase to our non-school customers at the price listed. Every effort will be made to sell this item at the lowest available price to our non-school customers. Please call us at (800) 831-5904.

This versatile metal ring roller makes a strong starter tube roll and ring roll machine. Use for coiling tubing, hay hoops, metal art, stair railings, and more. The 220-volt single-phase motor powers variable-speed inverter drives and industrial-grade transmission to provide delicate control over material. It has a 2" round tube and 1.5" schedule 40 pipe maximum capacity. Executes bends in upright or horizontal positions to accommodate a range of material lengths.

• Ratchet-style manual top shaft allows you to adjust forming pressure
• Sturdy base opens into a storage cabinet for tooling and other options
• Segment rolls can be used for bending flat bar, solid rod, and some square applications
• Manufactured from heavy steel plate to extend machine’s lifetime of use
• Steel plate construction maintains accuracy and minimizes flex
• Mfr.'s 1-year parts warranty plus lifetime technical support by phone

Roll Adjustment Manual: Pipe Capacity Size: 1.5" (sch. 40) / Min. Dia.: 28"
Round Tube Capacity Size: 2" (.078") / Min. Dia.: 27.55"
Square Tube Capacity Size: 1.5" (.078") / Min. Dia.: 39"
Solid Round Capacity Size: 1.375" / Min. Dia.: 24"
Flat Bar Easy Way Size: 3" (.5") / Min. Dia.: 15.75"
Flat Bar Hard Way Size: 2.25" (.375") / Min. Dia.: 20"
Angle Iron Capacity Size: 1.5" (.157") / Min. Dia.: 22"
Shaft Diameter: 1.181"
Shaft Center Distance Lower Rolls: 10.88"
Lower Roll Dia: 5.118"
Pinch: Single
Power: 220V Single Phase
Material Type: All Specs based on 60,000 PSI (42 Kg/mm 2) Tensile Strength– Mild Steel
Shipping Dimensions: 60" x 44" x 77"
Shipping Weight: 550 lbs.
