SawStop
36" Rip Capacity: ICS31230-ATGI36: 36" T-Glide Advance Fence Assembly
Overall saw dimensions: 69-1/4"W x 36-1/2"D x 34"H
Motor configuration 1: ICS31230: 3 HP, 1 phase, 230V, 13A, 60Hz, TEFC
Saw body footprint: 20"W x 25"D (Cabinet)
Cast iron table: 24"W x 30"D
Cast iron table (with extension wings): 44"W x 30"D
Extension wings: 10"W x 30"D each
Extension table 36": 24"W x 30"D
Shipping weights with 36" fence systems: 755 lbs. (4 boxes)
Shipping dimensions (saw body only): 40"W x 40"D x 40"H
Ship weight (approx.): 640 lbs. (table saw only)
Assembled weights: with 36" fence systems: 635 lbs. (approx. weight)
Weight table saw only: 530 lbs.
Blade: 40-tooth Titanium, 5/8" arbor
Blade diameter: 10"
Blade tilt: Left
Blade kerf: 0.118" (3mm)
Blade plate thickness: 0.078" (2mm)
Max. depth of cut, blade at 0°: 3-1/8"
Max. depth of cut, blade at 45°: 2-1/4"
Max. rip, right of blade- 36": 36"
Max. rip, left of blade: 12"
Dado diameter: 8" (requires dado brake cartridge and insert)
Dado max. width: 29/32"
Arbor diameter at blade: 5/8"
Arbor Runout: 0.001" Maximum allowable runout
Main bearing size: 62mm OD x 30mm ID
Second bearing size: 52mm OD x 25mm ID
Table in front of blade (max. elevation): 10-3/4"
Table behind blade (max. elevation): 10"
Arbor Runout: 0.001" Maximum allowable runout
Table flatness measured diagonally: 0.010" Maximum gap
Belts: 2 V-ribbed belts - arbor b. static dissipative
Blade alignment with miter slot: 0.010" Maximum displacement
Deviation of miter gauge indexing stops from actual: ±0.25°
Alignment between splitter and blade: 0.010" Maximum difference
Miter slots T-shaped: 3/4" at top, 1" at bottom, 3/8" deep
Miter slots center: 11-1/8" center-to-center
Miter slots info: 5-1/2" (arbor flange to center of right slot)
Dust collection port diameter: 4"
Dust collection blade guard: polycarbonate, extends only 1-3/16" to right of blade
Blade guard: (dust collection) port diameter 1-1/2" Outside, 1-1/4" Inside
Insert: zero clearance, phenolic core, melamine surfaces
Hand wheels: 8" diameter, cast iron with chrome handle
Riving knife/splitter thickness: 0.090" (2.3 mm)
Includes
2 Cast Iron Extension Wings
Miter Gauge
Dust Collection Blade Guard
Riving Knife
2 Blade Wrenches
Push Stick
10" Blade
Standard Lockdown Insert
Standard Brake Cartridge
Owner’s Manual
2 Hardware Packs
3mm Hex Key
5mm Hex Key
8mm Hex Key
Blade Spacing Adjustment Gauge
Ships in 4 boxes.
